• Air conditioning, single-zone
• Air vents, rear (Not available with Regular Cab model.)
• Assist handles front A-pillar mounted for driver and passenger, rear B-pillar mounted
• Audio system feature, 6-speaker system (Requires Crew Cab model.)
• Audio system, GMC Infotainment System with 7" diagonal color touch-screen, AM/FM stereo with seek-and-scan and digital clock, includes Bluetooth® streaming audio for music and select phones; featuring wired Android Auto and Apple CarPlay capability for compatible phones
• Back-up alarm calibration This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting
• Bluetooth® for phone, connectivity to vehicle infotainment system
• Door locks, power (Standard on Crew Cab models.)
• Driver Information Center, 3.5" diagonal monochromatic display
• Exterior Temperature Display, located in radio display
• Floor covering, rubberized-vinyl (Not available with LPO floor liners.)
• Mirror, inside rearview, manual tilt
• Power outlet, front auxiliary, 12-volt
• Seat adjuster, driver 4-way manual
• Seat adjuster, passenger 4-way manual
• Seat, rear 60/40 folding bench (folds up), 3-passenger, (includes child seat top tether anchor) (Not available with Regular Cab model.)
• Seats, front 40/20/40 split-bench with upper covered armrest storage and fixed lumbar (Standard on Crew Cab models only.)
• Steering column, Tilt-Wheel, manual with wheel locking security feature
• Steering wheel, urethane
• USB ports, 2 (first row) located on instrument panel
• Window, power front, passenger express down (Standard on Crew Cab models.)
• Windows, power front, drivers express up/down (Standard on Crew model.)
• Windows, power rear, express down (Not available on Regular Cab models.)

• Air filter, heavy-duty
• Air filtration monitoring
• Auto-locking rear differential
• Body, Chassis Cab
• Brakes, 4-wheel antilock, 4-wheel disc with DURALIFE rotors
• Capped Fuel Fill
• Four wheel drive
• Frame, fully-boxed, hydroformed front section and an open "C" rear section
• Fuel tank, front and rear, 63.5 gallon (240 liters)
• GVWR, 14,000 lbs. (6350 kg)
• Recovery hooks, front, frame-mounted, black
• Steering, Recirculating Ball with smart flow power steering system
• Suspension Package
• Transfer case, two-speed, electronic shift with push button controls (Requires 4WD models.)

• Airbags, dual-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Brake lining wear indicator
• Daytime Running Lamps, LED signature lighting
• Rear Seat Reminder (Requires Crew Cab model.)
• StabiliTrak, stability control system with Proactive Roll Avoidance and traction control, includes electronic trailer sway control and hill start assist
• Teen Driver a configurable feature that lets you activate customizable vehicle settings associated with a key fob, to help encourage safe driving behavior. It can limit certain available vehicle features, and it prevents certain safety systems from being turned off. An in-vehicle report card gives you information on driving habits and helps you to continue to coach your new driver
• Tire Pressure Monitoring System with Tire Fill Alert (does not apply to spare tire)

SPARE TIRE DELETE

• (STD)

SKID PLATES

• protect the oil pan
• front axle and transfer case

SNOW PLOW PREP PACKAGE

• includes (KW5) 220-amp alternator
• includes increased front GAWR on Heavy Duty models
• (NZZ) skid plates (transfer case and oil pan)
• pass through dash grommet hole and roof emergency light provisions. Contact GM Upfitter Integration at www.gmupfitter.com for plow installation details and assistance and includes (KW5) 220-amp alternator

PRO PREFERRED EQUIPMENT GROUP

• includes standard equipment

SEATS, FRONT 40/20/40 SPLIT-BENCH

• with upper covered armrest storage and fixed lumbar (STD)

CONVENIENCE PACKAGE

• includes (AQQ) Remote Keyless Entry
• (AKO) tinted glass
• (C49) rear-window defogger
• (DBG) outside power-adjustable vertical trailering with heated upper glass mirrors and (K34) cruise control

FUEL TANK, REAR ONLY, 40 GALLON

• mounted between frame side rails and behind rear axle Required for DEF tank relocation to inside the frame rails - includes DEF tank relocation mounting kit.)

AUDIO SYSTEM, GMC INFOTAINMENT SYSTEM WITH 7" DIAGONAL COLOR TOUCH-SCREEN, AM/FM STEREO

• with seek-and-scan and digital clock
• includes Bluetooth® streaming audio for music and select phones; featuring wired Android Auto and Apple CarPlay capability for compatible phones (STD)

REAR CAMERA KIT

• Kit includes camera
• fixed position bracket & 19 ft cable with attachment clips. Rear camera radio calibration provided from the factory. See Upfitter Integration Bulletin for installation instructions at www.gmupfitter.com

UPFITTER SWITCH KIT, (5)

• Provides 3-30 amp and 2-20 amp configurable circuits to facilitate installation of aftermarket electrical accessories. Kit with all required parts will be shipped loose with the truck for installation by the dealer or upfitter at customer expense. Installation instructions and technical assistance available at www.gmupfitter.com.

WI-FI HOTSPOT CAPABLE

• Terms and limitations apply. See onstar.com or dealer for details.)

SIRIUSXM RADIO

• enjoy a Platinum Plan trial subscription with over 150 channels including commercial-free music
• plus sports
• news and entertainment. Plus listening on the SiriusXM app
• online and at home on compatible connected devices is included
• so you'll hear the best SiriusXM has to offer
• anywhere life takes you. Welcome to the world of SiriusXM.

• ONSTAR AND GMC CONNECTED SERVICES CAPABLE
• SPARE TIRE DELETE (STD)
• SKID PLATES protect the oil pan front axle and transfer case
• LICENSE PLATE KIT FRONT
• SNOW PLOW PREP PACKAGE includes (KW5) 220-amp alternator includes increased front GAWR on Heavy Duty models (NZZ) skid plates (transfer case and oil pan) pass through dash grommet hole and roof emergency light provisions. Contact GM Upfitter Integration at www.gmupfitter.com for plow installation details and assistance and includes (KW5) 220-amp alternator
• CRUISE CONTROL STEERING WHEEL-MOUNTED
• TRANSMISSION ALLISON 10-SPEED AUTOMATIC
• REMOTE KEYLESS ENTRY
• PRO PREFERRED EQUIPMENT GROUP includes standard equipment
• SEATS FRONT 40/20/40 SPLIT-BENCH with upper covered armrest storage and fixed lumbar (STD)
• CONVENIENCE PACKAGE includes (AQQ) Remote Keyless Entry (AKO) tinted glass (C49) rear-window defogger (DBG) outside power-adjustable vertical trailering with heated upper glass mirrors and (K34) cruise control
• FUEL TANK REAR ONLY 40 GALLON mounted between frame side rails and behind rear axle Required for DEF tank relocation to inside the frame rails - includes DEF tank relocation mounting kit.)
• DEFOGGER REAR-WINDOW ELECTRIC
• AUDIO SYSTEM GMC INFOTAINMENT SYSTEM WITH 7" DIAGONAL COLOR TOUCH-SCREEN AM/FM STEREO with seek-and-scan and digital clock includes Bluetooth® streaming audio for music and select phones; featuring wired Android Auto and Apple CarPlay capability for compatible phones (STD)
• JET BLACK CLOTH SEAT TRIM
• REAR CAMERA KIT Kit includes camera fixed position bracket & 19 ft cable with attachment clips. Rear camera radio calibration provided from the factory. See Upfitter Integration Bulletin for installation instructions at www.gmupfitter.com
• WINTER GRILLE COVER
• GLASS DEEP-TINTED
• ENGINE BLOCK HEATER
• UPFITTER SWITCH KIT (5) Provides 3-30 amp and 2-20 amp configurable circuits to facilitate installation of aftermarket electrical accessories. Kit with all required parts will be shipped loose with the truck for installation by the dealer or upfitter at customer expense. Installation instructions and technical assistance available at www.gmupfitter.com.
• TRAILER BRAKE CONTROLLER INTEGRATED
• WI-FI HOTSPOT CAPABLE Terms and limitations apply. See onstar.com or dealer for details.)
• MIRROR INSIDE REARVIEW AUTO-DIMMING
• TIRES LT235/80R17E ALL-TERRAIN BLACKWALL
• SUMMIT WHITE
• REAR AXLE 3.42 RATIO
• MIRRORS OUTSIDE POWER-ADJUSTABLE VERTICAL TRAILERING with heated and auto-dimming upper glass (driver and passenger) lower convex mirrors turn signal indicators puddle lamps perimeter lighting auxiliary lighting manual folding and extending (extends 3.31" [84.25mm]) Includes (DD8) auto-dimming rearview mirror.)
• EXHAUST BRAKE
• SIRIUSXM RADIO enjoy a Platinum Plan trial subscription with over 150 channels including commercial-free music plus sports news and entertainment. Plus listening on the SiriusXM app online and at home on compatible connected devices is included so you'll hear the best SiriusXM has to offer anywhere life takes you. Welcome to the world of SiriusXM.
• SHIP THRU PRODUCED IN FLINT ASSEMBLY AND SHIPPED TO KNAPHEIDE TRUCK EQUIPMENT IN FLINT MI. RETURNED TO FLINT ASSEMBLY FOR SHIPPING TO FINAL DESTINATION
• ALTERNATOR 220 AMPS
• ENGINE DURAMAX 6.6L TURBO-DIESEL V8 B20-Diesel compatible (445 hp [332 kW] @ 2800 rpm 910 lb-ft of torque [1220 Nm] @ 1600 rpm) (Includes (K05) engine block heater.
• Locking/Limited Slip Differential
• Four Wheel Drive
• Tow Hooks
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Tires - Front All-Season
• Tires - Rear All-Season
• Steel Wheels
• Daytime Running Lights
• AM/FM Stereo
• MP3 Capability
• Bluetooth® Connection
• Auxiliary Audio Input
• Smart Device Integration
• Bluetooth® Connection
• Split Bench Seat
• Rear Bench Seat
• Floor Mats
• Adjustable Steering Wheel
• Power Windows
• Power Windows
• Power Windows
• Power Door Locks
• Power Outlet
• MP3 Capability
• Auxiliary Audio Input
• A/C
• Traction Control
• Stability Control
• Daytime Running Lights
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Passenger Air Bag Sensor
• Tire Pressure Monitor
• Driver Restriction Features

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14 x 1.6
• Rear Brake Rotor Diam x Thickness (in): 14 x 1.6
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 220
• Emissions
• Tons/yr of CO2 Emissions : 15K mi/year
• Exterior Dimensions
• Cab to Axle (in): 60
• Frame Width, Rear (in): 89.15
• Front Bumper to Back of Cab (in): 157.14
• Ground Clearance, Front (in): 8.15
• Ground Clearance, Rear (in): 8.15
• Height, Overall (in): 80.1
• Length, Overall (in): 270.3
• Wheelbase (in): 176.79
• Width, Max w/o mirrors (in): 80.84
• Frame
• Frame Type: Hydroformed Fully-Boxed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 40
• Fuel Tank Location: Rear
• Interior Dimensions
• Front Head Room (in): 43.03
• Front Hip Room (in): 61
• Front Leg Room (in): 44.53
• Front Shoulder Room (in): 66.02
• Passenger Capacity: 6
• Second Head Room (in): 40.12
• Second Hip Room (in): 61
• Second Leg Room (in): 43.4
• Second Shoulder Room (in): 65.3
• Steering
• Steering Type: Pwr Recirculating Ball
• Turning Diameter - Curb to Curb (ft): 57.5
• Summary
• Body Code: ZW9
• Body Style: Crew Cab Chassis Cab
• Vehicle Name: GMC Sierra 3500HD CC
• Suspension
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): 51
• Shock Absorber Diameter - Rear (mm): 51
• Stabilizer Bar Diameter - Front (in): 1.38
• Suspension Type - Front: Short Long Arm w/Torsion Bar
• Suspension Type - Rear: 3-Stage Multi-Leaf Spring
• Tires
• Front Tire Capacity (lbs): 2805
• Front Tire Order Code: QZT
• Front Tire Size: LT235/80R17E
• Rear Tire Capacity (lbs): 2833
• Rear Tire Order Code: QZT
• Rear Tire Size: LT235/80R17E
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Weight Information
• Curb Weight - Front (lbs): 4122
• Curb Weight - Rear (lbs): 2802
• Gross Axle Wt Rating - Front (lbs): 5600
• Gross Axle Wt Rating - Rear (lbs): 10500
• Gross Combined Wt Rating (lbs): 40000
• Gross Vehicle Weight Rating Cap (lbs): 14000
• Wheels
• Front Wheel Material: Steel
• Front Wheel Size (in): 17 x
• Rear Wheel Material: Steel
• Rear Wheel Size (in): 17 x
